BIOSIGNALS MONITORING

MADE EASY

Collect data outside the laboratory

BIOSIGNAL MONITORING

MADE EASY

ACQUIRE. STORE. ANALYZE.

The most efficient and flexible technology in the market to monitoring biosignals.
Developed by Mirai Innovation and featured in:

Explore the posibilities and build the future applications with AURA

ACQUIRE

Eight channels allow the acquisition of biosignals such as:
Electroencephalogram (EEG) signals (brain), Electromyogram (EMG) signals (muscle), Electroculogram (EOG) signals (eye), Electrocardiogram (ECG) (heart).



STORE

Store raw data in a simple file format such as CSV.
Storage location:
Removable microSD card – up to 64 GB. Transmit wirelessly to computer or smart device for visualization and recording

ANALYZE

Analyze biosignal data having the option of using your software packages of choice, including: AURA visualization, MATLAB and EEGLAB – open source EEG toolkit for MATLAB.

AURA provide multiple benefits
to persons in different enviroments like health, education, and business.

Two flexible operation modes

Record or stream

On Board Storage

High Capacity SD Card

Remote Storage

Bluetooth Transmission

Real time

Streaming and Visualization

Standard data format

CSV file

Real time clock

Accurate file date and timestamps

Fast transmission

Up to 300kbps

Event Marker

Button Event Marker

Impedance Check

Online Impedance Check Mode

Signal Visualization Software

Innovative Visualization Suite

TECHNICAL SPECIFICATIONS

  • 8 CHANNELS DIN42802 Connectors (Online impedance check mode)
  • 250 Hz Sampling frequency (Up to 300kbps)
  • Gyro and accelerometer (6 Degrees of freedom)
  • USB Rechargeable Lithium Battery (LED Indicator)
  • Bluetooth 2.1 (USB BT dongle included)
  • 2 Push Buttons (Control buttons for operation mode and event markers)
  • microSD Card slot (8 Gb card included)
  • 24-BIT DELTA-SIGMA ADC (High signal to Noise Ratio)
